Our energy efficient project

2009 Sustainable energy efficient conversion and extension in Ideford Devon



Design and drawn by Tom Foster www.tomfosterarchitecture.co.uk

This project was a true sustainable build,using timbers from the surrounding woodland. The existing 300 year old mill was upgraded with 200 mm EPS EWI system that was extended down into the ground and up into the roof over the wall plate to connect to the roof insulation.

The new extension incorporated an insulated raft foundation with Tom Foster’s hybrid wall construction of 150mm timber frame with Osb3 Smartply external sheathing and plasterboard internal full filled with Warmcell500 and externally bonded 150mm EPS70 counter-battened and timber cladding.

Indicative Uvalue 0.14W/m2K Roof construction is similar to walls with natural slate cover. Cold bridging was addressed by connecting seamlessly the outer layer of 150mm EPS wall insulation to the insulation from the foundations. Windows and doors were Russel timber Tech triple glazed eco contract range.

2011 Sustainable energy efficient extension in longwell green, Bristol



Design and drawn by Tom Foster www.tomfosterarchitecture.co.uk

Description: This project tackled the problems of a restricted site with limited access. An innovative timber foundation and timber frame super structure, less than 1/2m3 of concrete was used in the substructure to form leveling pads that supported reclaimed Jarrah crossing sleepers as foundation beams with timber joists and timber frame superstructure above.

The new extension incorporated an insulated foundation using 400mm of Lecaexpanded clay,with Tom Foster’s hybrid wall construction of 150mm timberframe with Osb3Smartply external sheathing and plasterboard internal and fulfilled with Warmcell500and externally bonded 150mm EPS70 coated in Parex lightweight render system.

IndicativeUvalue 0.14W/m2K
Roof construction is similar to walls with corragatedcoatedsheetcover. Cold bridging was addressed by connecting seamlessly theouter layer of150mm EPS which also connect to the insulation from thefoundations.
Windows and doors were triple glazed UPVC

2013 A low energy extension and complete overhaul of existing 300 year old cottage



Designed and drawn by myself

Description: This was our own family home, a 300 year old cottage in need of future-proofing The existing drafty, single glazed, solid stone cottage was full of character and charm but unbearably cold in winter and painfully expensive to heat.

So we planned a full retrofit project for the cottage and a large glassy extension.
